1. Scope of Application

This specification describes the outline dimensions, performance indicators, technical requirements and precautions for use of the RD600W-B portable energy storage power supply.

2. Power Supply Composition

Model	Cell Type	BMS Model	Inverter Type
IP600W Portable Energy Storage Power Supply	3.2V LFP(LiFePO₄)	6S 60A	19.2VDC to 220VAC

3. Power Supply Performance Indicators

Item	Parameter	Index	Remarks
Battery Pack	Nominal Voltage (V)	19.2	—
	Nominal Capacity (Ah)	28	537.6Wh
	Minimum Capacity (Ah)	26.6	510.7Wh
	Min Discharge Cut-off Voltage (V)	16.2	—
	Max Continuous Discharge Current (A)	≤40	—
	Max Charging Voltage (V)	21.9	—
	Max Charging Current (A)	≤10	—
	Cycle Life	1. Charging: 0.2C charge to 21.1V	1200 cycles ≥80% initial capacity
		2. Constant voltage to 0.02C, stand for 30min
		3. Discharging: 0.2C discharge to 16.2V
		4. Standing: 30min
		5. Temperature: 25±2℃
	Internal Resistance(mΩ)	＜100	AC 1kHz
DC Input (Charging)	DC5521 Charging Port	120W Max（DC12~24V/5A） Support charging with mains electricity, car, charger, and photovoltaic
	TYPE-C Charging Port	TYPE-C PD100W Max
	Charging Time	4-6H
AC Output	Output Interface	600W	1 piece
	Rated Voltage/Frequency	220V/50HZ	Pure sine wave (harmless to appliances)
	Output Power	Rated 600W / Peak 1200W	—
DC Output	Output Interface	1×Cigarette lighter, 2×DC5525	—
DC Output	Output Power	Total 120W Max	12V 10A Max
LED Light	Output mode	LED Light / SOS	1 piece
Wireless Charging (Optional)		15W Max	—
USB Output	QC3.0	18W	1 piece
	TYPE-C	PD18W	1 piece
	TYPE-C	PD100W	1 piece
Display		Battery percentage, bar, status, power
Conversion Efficiency		≥85%	—
Weight (Kg)		Approx. 7Kg	—
Product Size (mm)		270210230mm	—
Color		Gray (custom is available)	—
Protection		Over-charge / Over-discharge / Over-current / Short-circuit / Balance / Temperature Protection
Working Temp (℃)	Charge/Discharge	0℃~45℃	—
Working Temp (℃)	Optimal Temp	10℃~35℃	—
Storage Temp & Humidity	Short-term (≤1 month)	-20℃~50℃	Humidity: 65%±20% RH
	Short-term (≤1 month)	-20℃~50℃
	Short-term (≤3 months)	-20℃~35℃
	Short-term (≤12 months)	-20℃~25℃
	Long-term (＞12 months)	15℃~25℃
Heat Dissipation		Intelligent air cooling	Recover after 2h cooling at room temp

4. Power Supply Structure Diagram

4.1 Power Supply Structure Drawing

Product Size：270mm×210mm×230mm

4.2 Panel Layout

No.	Name	No.	Name
1	Display screen	9	PD100W Input/Output
2	Mains switch	10	PD18W Output
3	LED switch	11	AC switch
4	DC switch	12	AC output
5	DC5525 output	13	DC5521 charging port
6	Car charger output	14	LED light
7	USB switch	15	Wireless charging (optional)
8	QC3.0 output	—	—

5. Battery Management System

The built-in lithium battery protection board can monitor the battery operation status in real time. It will cut off input and output for protection when over-charge, over-discharge, over-current, over-temperature occurs.

BMS Performance Parameter Table

Item	Details	Standard
Single Cell Over-charge Protection	Detection Voltage	3.75±0.03V
	Delay Time	500~1500mS
	Recovery Voltage	3.55±0.05V
Single Cell Over-discharge Protection	Detection Voltage	2.2±0.1V
	Delay Time	4000~6000mS
	Recovery Voltage	2.7±0.1V
Over-current Protection	Charging Over-current Protection Value	220±60A
	Level 1 Discharge Over-current Value	270±80A
	Level 2 Discharge Over-current Value	680±150A
	Charging Over-current Release	Remove Charger
	Discharge Over-current Release	Disconnect Load / Resume by Charging
Short-circuit Protection	Protection Condition	External Circuit Short Circuit
	Delay Time	200~800uS
	Release Condition	Disconnect Load / Resume by Charging
Cell Temp Protection	Discharge High-temperature Protection	70℃±10℃
Cell Temp Protection	Discharge High-temperature Recovery	50℃±10℃
Quiescent Current	Power Consumption	≤100μA
Quiescent Current	Loop Internal Resistance	≤10mΩ
Balance Function	Balance Enable Voltage	3.5±0.05V
Balance Function	Balance Current	200±50mA

6. Transportation and Storage Precautions

For long-term storage, complete a charge-discharge cycle every 3 months. Do not drop during handling; stacking shall not exceed 4 layers; do not place upside down, keep front side upward.

7. Warnings and Notes

Please read the specification and warning marks on the power supply carefully before use. Improper use may cause overheating and damage of the power supply. Jiangmen Ronda Lithium Battery Co., Ltd. shall not be liable for any accidents caused by non-standard operation. Please follow the instructions for safe use.

Warning

Keep the power supply away from heat sources and high-voltage places, avoid long-term direct sunlight exposure.
The product contains high-voltage components. Do not disassemble it privately to avoid safety accidents.
Do not put the power supply into water or fire.
Do not reverse the positive and negative poles of the power supply. Do not short-circuit the positive and negative poles with metal objects.
Avoid severe physical vibration and impact; do not hit, drop or step on the power supply.
Disassembly or assembly without manufacturer permission and guidance is strictly prohibited.
Do not use power supplies of different manufacturers, types and models in combination.

Note

The load equipment must meet two conditions for use: ① Input power < rated power of power supply; ② Starting power at boot < peak power of power supply.
The power supply will automatically activate protection and turn off output when low battery, excessive load power or over ambient temperature.
Please charge the power supply within 15 days after being exhausted.

Use matched or recommended professional lithium battery charger only.

Stop using immediately if abnormal conditions such as peculiar smell, discoloration, abnormal noise, liquid leakage or severe deformation occur.
If electrolyte leaks and splashes on skin or eyes, rinse with clean water immediately and seek medical treatment.
Place the power supply out of reach of pets and children; keep children away from the product.
It is forbidden to use multiple units in series or parallel connection. Please contact the manufacturer for consultation if series/parallel application is required.

8. Packing List

No.	Material Name	Unit	Quantity
1	Portable Power Station	PCS	1
2	User Manual	PCS	1
3	Power Adapter	PCS	1

9. Certifications

This portable power station complies with CE, FCC, UN38.3, MSDS standards.

10. Safety Compliance

Designed per IEC62619 for lithium iron phosphate battery safety; built-in multi-protection circuits including over-charge, over-discharge, over-current, short-circuit and over-temperature protection to meet international safety requirements.
